Overview
M8 PHEV New
A Luxurious Masterpiece
372
Combined Maximum Output
(PS)
(PS)
630
Combined Max Torque
(Nm)
(Nm)
1.1
Fuel Consumption
(ℓ / 100km)
(ℓ / 100km)
1038
Combined Driving Range*
(km)
(km)
RM388,800
*On The Road Without Insurance
372
Combined Maximum Output
(PS)
(PS)
630
Combined Max Torque
(Nm)
(Nm)
1.1
Fuel Consumption
(ℓ / 100km)
(ℓ / 100km)
1038
Combined Driving Range*
(km)
(km)
RM328,800
*On The Road Without Insurance
CRAFTED TO IMPRESS
A luxurious and spacious MPV designed for comfort and elegance, M8 PHEV provides an unparalleled blend of style, comfort, and cutting-edge technology, all underpinned by our unwavering commitment to quality and reliability. Every detail of M8 PHEV is meticulously crafted to evoke a sense of luxury.
CRAFTED FOR COMFORT & ELEVATE
The M8 PHEV's interior design exudes luxury and sophistication, tailored to offer exceptional comfort and elegance. The cabin features premium materials, including high-quality leather and soft-touch surfaces, creating an upscale atmosphere. Advanced technology and thoughtful ergonomics ensure a user-friendly experience, while ample space and flexible seating configurations provide versatility for both family and business usage
CRAFTED FOR PERFORMANCE
CRAFTED FOR SAFETY
MAGAZINE BATTERY
Tested against puncture, compression, and thermal runaway scenarios, the Magazine Battery ensures exceptional safety by maintaining stability and preventing fire even under extreme pressure or collision.
|
SPECIFICATIONS
|
LUXURY | PREMIUM |
MECHANICAL PERFOMANCE
| Engine Type | 2.0TM In-line 4, 16-valve DOHC, Turbocharged / 1991(cc) | |
| Engine Max Output (PS / RPM) | 190 / 5000 | |
| Engine Max Torque (Nm / RPM) | 330 / 1500 – 4000 | |
| Motor Type | Permanent Magnet Synchronous Motor | |
| Motor Max Output (PS / RPM) | 182 / 5000 | |
| Motor Max Torque (Nm) | 300 | |
| Combined Max Output (PS) | 372 | |
| Combined Max Torque (Nm) | 630 | |
| Transmission | 2-speed Dedicated Hybrid Transmissions (DHT) | |
| Pure Electric Driving Range (km) | 120 | |
| Fuel Consumption Combined (ℓ / 100km) | 6.1 | |
| Hybrid Consumption Combined (ℓ / 100km) | 1.1 | |
| Combined Driving Range (km) | 1038 | |
| Acceleration 0 – 100 km/h (seconds) | 8.8 | |
| Length x Width x Height (mm) | 5212 x 1893 x 1823 | |
| Wheelbase (mm) | 3070 | |
| Kerb Weight (kg) / Gross Vehicle Weight (kg) | 2420 / 3000 | |
| Ground Clearance (mm) | 143 | |
| Fuel Tank Capacity (ℓ) | 56 | |
| Min. Turning Radius (m) | 6.6 | |
| Tyres & Wheels | 225 /60 R18, Alloy | |
| Acoustic Tyres | ● | - |
| Self-Leveling Wheel Caps | ● | ● |
| Tyre Inflation Kit | Front: MacPherson Suspension | |
| Suspension System | Rear: Multi-link Suspension | |
| Steering System | Electric Power Steering (EPS) | |
| Driving Mode | Eco / Comfort / Sport | |
| Brakes | Front and Rear: Ventilated Disc | |
BATTERY
| Battery Type | Magazine Battery | |
| Battery Capacity (kWh) | 25,57 | |
| Charging (kW) | AC: 6.6kW / DC: 40kW | |
| V2L (kW) | 3,3 | |
EXTERIOR
| LED Headlights with Welcome Home Function | ● | ● |
| LED Daytime Running Lights | ● | ● |
| Automatic Headlights with High Beam Assist (HMA) | ● | ● |
| Connected LED Tail Lights with Dynamic Light Sequence | ● | ● |
| Power Adjustable Side Mirrors with Heating, Curb View and Memory Function | ● | ● |
| Auto-folding Exterior Rear View Mirrors | ● | ● |
| 2nd and 3rd Row Side Windows and Rear Windscreen | Acoustic Privacy Glass | |
| Front Sunroof with Tilting, Slide Opening and Sunshade | ● | ● |
| Rear Sunroof with Electric Sunshade | With Starlight | ● |
| Hands-Free Power Tailgate with Remote Opening | ● | ● |
| Rain Sensing Front Windscreen Wipers with Integrated Windscreen Washer | ● | ● |
| Rear Windscreen Wiper | ● | ● |
INTERIOR
| Passive Entry Passive Start (PEPS) | ● | ● |
| 12.3" Instrument Cluster | ● | ● |
| Multifunction Leatherette Steering Wheel with Tilt and Telescopic Adjustment | ● | ● |
| Crystal Gear Shift Selector | ● | ● |
| Interior Trim | Black & Red | Brown |
| Premium Suede Headliner | Beige | Black |
| Dual Electric Sliding Door with Anti-Pinch | ● | ● |
| Welcome Lights | Light Carpet | Puddle Lamp |
| 3-Zone Climate Control System | ● | ● |
| Draft-Free Air Conditioning Roof Vents | ● | ● |
| Air Ionizer with Air Quality Sensor (AQS) and PM 2.5 Filter | ● | ● |
| Fragrance System | ● | - |
| Front Central Armrest with Heating and Cooling Cup Holder | ● | ● |
| Seat Upholstery (Driver, Passenger & 2nd Row) | Semi-Aniline Leather | Leather |
| Seat Upholstery (3rd Row) | Leather | Leatherette |
| Seat Ventilation and Heated Function | Driver, Passenger & 2nd Row | |
| Seat Belt with Pretensioners, Force Limiters | Driver, Passenger & 2nd Row | |
| Seat Belt Reminder (Visual & Audio) | Driver, Passenger & 2nd Row | |
| ISOFIX Child Seat Anchorage – i-Size | 2nd & 3rd Row | |
| Driver: Seat Adjustment | 12-Way Electric | |
| Driver: Headrest Adjustment | 4-Way | 2-Way |
| Driver: Seat Alertness System | ● | - |
| Driver: Easy Entry & Exit | ● | ● |
| Passenger: Seat Adjustment | 4-Way Electric | |
| Passenger: Headrest Adjustment | 4-Way | 2-Way |
| Passenger: Boss Switch | ● | - |
| 2nd Row: Seat Controller | Touch Screen | Capacitive Touch |
| 2nd Row: Seat Adjustment | 6-Way Electric | 4-Way Electric |
| 2nd Row: Sliding Adjustment | 2-Way Electric | 2-Way |
| 2nd Row: Headrest Adjustment | 4-Way | |
| 2nd Row: Tray Table | ● | - |
| 2nd Row: Massage Function | 3 Modes | 1 Mode |
| 2nd Row: One-Touch SPA Mode | ● | - |
| 2nd Row: Cup Holder | 1/Seat | |
| 2nd Row: Smartphone Storage | ● | ● |
| 2nd Row: Easy Entry & Exit | ● | ● |
| 3rd Row: Seat Adjustment | 4-Way | |
| 3rd Row: Headrest Adjustment | 2-Way | |
| 3rd Row: 60:40 Split Folding | ● | ● |
| 3rd Row: Armrest | ● | ● |
| 3rd Row: Outer Seat Belt with Pretensioners and Force Limiter | ● | ● |
| 3rd Row: 3-Point Middle Seat Belt | ● | ● |
| All Power Door Windows with Anti-Pinch | ● | ● |
| Second Row Sunshade | ● | - |
| Auto-Dimming Rear View Mirror | ● | ● |
| Vanity Mirror with LED Light | ● | ● |
| LED Reading Lights | Adjustable | |
| Multi-Colour Ambient Lighting | ● | - |
ENTERTAINMENT AND TECHNOLOGY
| 10.1" Multifunctional Touch Screen with Yamaha Premium 8-Speakers Sound System | ● | ● |
| Android Auto / Mirrorlink & Wireless Apple CarPlay™ | ● | ● |
| 50W Wireless Smartphone Charger | ● | ● |
| USB-A | 5 | 4 |
| USB-C | 3 | |
| Power Socket | 12V & 3-pin | 12V |
SAFETY
| Dual Front SRS Airbags | ● | ● |
| Front Side Airbags | ● | ● |
| Side Curtain Airbags | ● | ● |
| Rear Windshield Airbag | ● | ● |
| Safe Speed Reminder | ● | ● |
| Sliding Door Child Lock | ● | ● |
| Anti-lock Braking System (ABS) with Electronic Brakeforce Distribution (EBD) | ● | ● |
| Electronic Stability Program (ESP) | ● | ● |
| Hydraulic Brake Assist (HBA) | ● | ● |
| Electronic Parking Brake with Autohold | ● | ● |
| Hill Hold Control (HHC) | ● | ● |
| Hill Descent Control (HDC) | ● | ● |
| Acoustic Vehicle Alert System (AVAS) | ● | ● |
| Parking Sensors | Front: 6 / Rear: 6 | Front: 2 / Rear: 4 |
| 360° Surround View Camera System with Transparent Chassis | ● | ● |
| Tire Pressure Monitoring System (TPMS) | ● | ● |
ADVANCED DRIVER ASSISTANCE SYSTEMS
| Integrated Cruise Assist (ICA) | ● | ● |
| Traffic Jam Assist (TJA) | ● | ● |
| Adaptive Cruise Control (ACC) | ● | ● |
| Automatic Emergency Braking (AEB) | ● | ● |
| Forward Collision Warning (FCW) | ● | ● |
| Lane Keep Assist (LKA) | ● | ● |
| Lane Departure Warning (LDW) | ● | ● |
| Emergency Lane Keeping Assist (ELKA) | ● | ● |
| Intelligence Avoidance (IA) | ● | ● |
| Blind Spot Detection (BSD) | ● | ● |
| Door Opening Warning (DOW) | ● | ● |
| Rear Automatic Emergency Braking (RAEB) | ● | - |
| Rear Car Approaching Warning (RAW) | ● | ● |
| Rear Cross Traffic Braking (RCTB) | ● | ● |
| Rear Cross Traffic Alert (RCTA) | ● | ● |
| Traffic Sign Recognition System (TSR) | ● | ● |
| Reverse Tracking | ● | - |
| Smart Damping Control (SDC) | ● | - |
| Adaptive Vehicle Dynamic Control (AVDC) | ● | ● |
| Full Automatic Parking Assist (FAPA) | ● | - |
- “●”-Standard；“-”-N/A
- The specifications above are subject to change without prior notice.
- WTC Automotif (M) Sdn. Bhd. reserves the right to change specifications without prior notice.
- The illustrations may show accessories and optional extras which are not part of standard specification.
- Official data for fuel consumption are based on New European Driving Cycle (NEDC) obtained under specific testing conditions. The real-life fuel consumption achieved under real conditions varies depending on driving behaviour and other external factors.
- Figures for rated output and rated torque are based on engine measurements.
